Analog Devices Inc. AD8264-EVALZANALOG DEVICES AD8264-EVALZQUAD_100 MHZ DC COUPLED VGA

Analog Devices Inc. AD8264-EVALZ Reference Design 3

Analog Devices Inc. AD8264-EVALZ Reference Design 1

Analog Devices Inc. AD8264-EVALZ Reference Design 2

Applications:

Amplifiers and Comparators >

Difference Amplifier

End Products:

Instrumentation and MeasurementInstrumentation and Measurement

ECAD Model:

Buy

Description

The Analog Devices AD8264-EVALZ Evaluation Board is designed for use with the AD8264 Quad, 235 MHz, DC-Coupled VGA and Differential Output Amplifier. This board is ideal for instrumentation and measurement applications, providing a high-performance, low-noise amplifier with a wide dynamic range. The board features a wide range of adjustable gain and bandwidth settings, allowing for precise control of the amplifier's output. The board also includes a differential output amplifier, allowing for the connection of multiple devices to the same amplifier. The AD8264-EVALZ Evaluation Board is a great choice for any instrumentation or measurement application.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .

Type
Parameter
Lifecycle Status
PRODUCTION (Last Updated: 3 months ago)
Factory Lead Time
8 Weeks
Number of Pins
0
Packaging
Box
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Base Part Number
AD8264
Output Type
Differential
Operating Supply Voltage
5V
Number of Channels
4
Interface
Parallel, Serial
Operating Supply Current
99mA
Nominal Supply Current
99mA
Slew Rate
380V/μs
Amplifier Type
Variable Gain
Voltage - Supply, Single/Dual (±)
±2.5V~5V
Utilized IC / Part
AD8264
Supplied Contents
Board(s)
Evaluation Kit
Yes
Gain
24 dB
-3db Bandwidth
235MHz
Board Type
Fully Populated
Channels per IC
4 - Quad
Current - Supply (Main IC)
99mA
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
Lead Free
Contains Lead

0 Similar Products Remaining

Technical Documents

Associated Products

Part Number	Manufacturer	Description	Stock	RFQ
