ON Semiconductor A5191HRTNGEVBON SEMICONDUCTOR A5191HRTNGEVB Evaluation Board, A5191HRT, Hart Modem, Single Chip, Low Power, Receive Band Pass Filter

ON Semiconductor A5191HRTNGEVB Reference Design 4
ON Semiconductor A5191HRTNGEVB Reference Design 1
ON Semiconductor A5191HRTNGEVB Reference Design 2
ON Semiconductor A5191HRTNGEVB Reference Design 3
ON Semiconductor A5191HRTNGEVB Reference Design 4
ON Semiconductor A5191HRTNGEVB Reference Design 1
ON Semiconductor A5191HRTNGEVB Reference Design 1
ON Semiconductor A5191HRTNGEVB Reference Design 2
ON Semiconductor A5191HRTNGEVB Reference Design 3
ON Semiconductor A5191HRTNGEVB Reference Design 4

Applications:

Wired Communication >

Modems

End Products:

Communications and TelecomModems

ECAD Model:

Buy

Description

The Onsemi A5191HRTNGEVB-HRTNGEVB Hart Modem QFN Evaluation Board is a communications and telecom device designed to evaluate the performance of the Onsemi A5191 Hart Modem. It is a compact, low-cost evaluation board that allows users to quickly and easily evaluate the performance of the A5191 Hart Modem. The board includes a QFN package, a power supply, and a USB interface for easy connection to a PC. The board also includes a variety of test points and connectors for easy evaluation of the modem's performance. The board is ideal for use in industrial, automotive, and medical applications.

Specifications

ON Semiconductor technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor .
  • Type
    Parameter
  • Factory Lead Time
    6 Weeks
  • Package / Case
    QFN
  • Published
    2011
  • Part Status
    Active
  • Moisture Sensitivity Level (MSL)
    1 (Unlimited)
  • Type
    Telecom
  • Max Operating Temperature
    85°C
  • Min Operating Temperature
    -40°C
  • Function
    Modem
  • Operating Supply Voltage
    5.5V
  • Interface
    UART
  • Data Rate
    1.2 kbps
  • Utilized IC / Part
    A5191HRT
  • Supplied Contents
    Board(s)
  • Evaluation Kit
    Yes
  • Primary Attributes
    Single-Chip, Half-Duplex, 1200 Bits Per Second FSK Modem
  • Embedded
    No
  • REACH SVHC
    No SVHC
  • RoHS Status
    ROHS3 Compliant
