Analog Devices LTC3707EGN#PBF

DC DC Converter 4.5V ~ 28V 28-SSOP (0.154, 3.90mm Width) Transistor Driver 2 Outputs Tube DC DC Switching Controller

Manufacturer No:

LTC3707EGN#PBF

Manufacturer:

Analog Devices

Utmel No:

153-LTC3707EGN#PBF

Package:

28-SSOP (0.154, 3.90mm Width)

ECAD Model:

Description:

4.5V ~ 28V 28-Pin DC to DC converter IC SWITCHING CONTROLLER 2 Outputs 220kHz Transistor Driver
