Analog Devices Inc. AD8556-EVALZANALOG DEVICES AD8556-EVALZAD8556 EVALUATION MODULE

Analog Devices Inc. AD8556-EVALZ Reference Design 4
Analog Devices Inc. AD8556-EVALZ Reference Design 1
Analog Devices Inc. AD8556-EVALZ Reference Design 2
Analog Devices Inc. AD8556-EVALZ Reference Design 3
Analog Devices Inc. AD8556-EVALZ Reference Design 4
Analog Devices Inc. AD8556-EVALZ Reference Design 1
Analog Devices Inc. AD8556-EVALZ Reference Design 1
Analog Devices Inc. AD8556-EVALZ Reference Design 2
Analog Devices Inc. AD8556-EVALZ Reference Design 3
Analog Devices Inc. AD8556-EVALZ Reference Design 4

Applications:

Amplifiers and Comparators >

Instrumentation Amplifier

End Products:

Instrumentation and MeasurementSpeed DetectionPosition SensorMagnetic Measurement

ECAD Model:

Buy

Description

The Analog Devices AD8556-EVALZ is an evaluation board for the AD8556 Zero-Drift, Digitally Programmable Sensor Signal Amplifier, Instrumentation and Measurement Amplifier. This board is designed to provide a platform for evaluating the performance of the AD8556 amplifier. It features a wide range of gain settings, adjustable offset, and a low-noise, low-power design. The board also includes a variety of connectors and test points for easy connection to external components. The AD8556-EVALZ is an ideal tool for evaluating the performance of the AD8556 amplifier in a variety of applications.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .
  • Type
    Parameter
  • Lifecycle Status
    PRODUCTION (Last Updated: 2 weeks ago)
  • Factory Lead Time
    8 Weeks
  • Package / Case
    SOIC
  • Number of Pins
    0
  • Series
    DigiTrim®
  • Part Status
    Active
  • Moisture Sensitivity Level (MSL)
    1 (Unlimited)
  • Max Operating Temperature
    125°C
  • Min Operating Temperature
    -40°C
  • Base Part Number
    AD8556
  • Output Type
    Single-Ended
  • Operating Supply Current
    2.7mA
  • Nominal Supply Current
    2.7mA
  • Slew Rate
    1.2V/μs
  • Amplifier Type
    Chopper (Zero-Drift)
  • Common Mode Rejection Ratio
    80 dB
  • Voltage - Supply, Single/Dual (±)
    4.5V~5.5V
  • Output Current per Channel
    10mA
  • Utilized IC / Part
    AD8556
  • Supplied Contents
    Board(s)
  • Input Offset Voltage (Vos)
    10μV
  • Evaluation Kit
    Yes
  • Board Type
    Fully Populated
  • Channels per IC
    1 - Single
  • Current - Supply (Main IC)
    2mA
  • REACH SVHC
    No SVHC
  • RoHS Status
    ROHS3 Compliant
  • Lead Free
    Contains Lead
