Analog Devices Inc. ADL5240-EVALZANALOG DEVICES ADL5240-EVALZEvaluation Board for ADL5240 RF/IF Digitally Controlled VGA

The Analog Devices ADL5240-EVALZ Evaluation Board is designed to evaluate the performance of the ADL5240 100 to 4000 MHz RF/IF Digitally Controlled Variable Gain Amplifier (VGA). This board is ideal for instrumentation and measurement applications, providing a wide range of gain control and excellent linearity. The board features a wide range of gain control, from -20 dB to +20 dB, and a low noise figure of 1.5 dB. It also features a wide bandwidth of 100 to 4000 MHz, making it suitable for a variety of applications. The board is designed to be used with a single +5V supply, and includes a USB interface for easy connection to a PC. The board also includes a variety of test points and connectors for easy evaluation and testing.
