IRAMX20 series High-current integrated power modules are a kind of intelligent power module (IPM) produced by the International Rectifier Corporation for driving motors and other applications. These modules integrate the inverter drive and protection circuitry in a single package using IR advanced IGBT, ultra-soft recovery diodes, and rugged gate driver HVIC.
Features
The main features of IRAMX20 series High-current integrated power modules may be summarized as follows:
1. Blocking voltage of 600V
2. Output current of 10A or 15A
3. Switching frequency of 20kHz
4. SIP-2 package
5. Built-in over-temperature, over-voltage, short-circuit, and under-voltage protection functions
6. Suitable for applications such as air conditioners, fans, compressors, and washing machines
Applications
They can simplify and shrink the motor drive design, and improve system performance and reliability for home appliances and industrial applications.
