C0G series ceramic capacitors are surface mount multilayer ceramic chip capacitors (SMD MLCC) manufactured using C0G dielectric with high Q, low loss angle tangent, high stability, and high reliability. They also incorporate KEMET's innovative technologies such as KONNEKT technology and FT-CAP technology to improve package density and mechanical strength.
Features
The main features of C0G series Ceramic capacitors may be summarized as follows:
1. C0G dielectric is a stable, temperature-compensated, Class I material suitable for resonant circuit applications.
2. Operating temperature range of -55°C to +125°C.
3. RoHS and REACH are compliant and lead-free.
4. EIA 0201, 0402, 0603, 0805, 1206, 1210, 1808, 1812, 1825, 2220, and 2225 these package sizes.
5. Voltage ratings are 10 V, 16 V, 25 V, 50 V, 100 V, 200 V, and 250 V.
6. Capacitance values range from 0.5 pF to 0.47 μF with tolerances of ±0.10 pF, ±0.25 pF, ±0.5 pF, ±1%, ±2%, ±5%, ±10% and ±20%.
7. No piezoelectric noise, extremely low equivalent series resistance (ESR), and equivalent series inductance (ESL)
8. High thermal stability, and high ripple current capability.
Applications
High-frequency and microwave circuits, such as oscillators, filters, amplifiers, mixers, etc.
High-efficiency and high-density power applications such as switch mode power supplies (SMPS), DC-DC converters (DC-DC), inverters, etc.
Automotive applications, such as powertrain, in-vehicle electronics, charging systems, etc.
