For applications needing high power contacts and signal interconnects, Molex Mega-Fit series Connector Kits are a line of dependable, high-performance power connectors. The kits include a sturdy housing design that safeguards the connector system's integrity and protects against unintentional unmating.
Positive-locking features are provided by Mega-Fit connectors to avoid unintentional disengagement under shock and vibration situations, lowering downtime and repair costs. A wide range of industrial, telecom, data center, and automotive applications can use the connectors in the product line, which come in circuit sizes ranging from 2 to 24 circuits.
The Mega-Fit series Connector Kits have passed industry standards like UL 1977 and have been tested for use over a wide temperature range (-40°C to +105°C). The kits also include anti-snag terminal designs for hassle-free assembly and removal, color-coded mechanical keying to prevent mismating, and tool-free assembly to cut down on installation time and expense.
All things considered, Molex Mega-Fit series Connector Kits offer a dependable, high-performance solution for power and signal interconnects across numerous industries. They are a popular option for designers looking for affordable high-power solutions due to their features including positive-locking housings, high power contacts, anti-snag terminals design, broad temperature range, and tool-less installation.
Features
Mega-Fit connectors are suited for high-power applications because they can carry up to 23A per circuit.
Positive-locking housings are protective against unintentional unmating and offer increased security to guard against harm to the connector system.
Several Circuit Sizes: The kits come in a range of circuit sizes, ranging from 2 to 24 circuits, allowing designers to select the one that is most appropriate for their application.
Wide Temperature Range: Mega-Fit connector kits have been evaluated for use over a wide temperature range (-40°C to +105°C) and are compliant with UL 1977, among other industry standards.
Color-coded Mechanical Keying: To avoid mismating, Mega-Fit male and female connections include different mechanical keying.
Anti-Snag Terminal Design: The anti-snag function makes sure that during installation or removal, the terminals won't cling to the housing.
Tool-less Assembly: The kits are made to be assembled without the use of tools, thereby cutting down on both the cost and time of installation.
For power and signal interconnects in a variety of applications, including industrial equipment, networking, telecom, and data centers, Molex Mega-Fit Connector Kits offer a dependable, high-performance solution. The kits are a great option for high-reliability power connections because to their combination of high power contacts, protective enclosure, different circuit sizes, wide temperature range, color-coded mechanical keying, anti-snag terminal design, and tool-less assembly.
Applications
Data Centers
Medical Devices
Industrial Equipment
Consumer Electronics
Networking and Telecom
Automotive and Transportation
Overall, the Molex Mega-Fit series Connector Kits offer a reliable, cost-effective solution for power and signal interconnects in various applications requiring high power contacts, protective housing, multiple circuit sizes, and tool-less assembly.
