Analog Devices LTC3851AIUD#PBF

DC DC Converter 4V ~ 38V 16-WFQFN Exposed Pad Transistor Driver 1 Outputs Rail/Tube DC DC Switching Controller

Manufacturer No:

LTC3851AIUD#PBF

Manufacturer:

Analog Devices

Utmel No:

153-LTC3851AIUD#PBF

Package:

16-WFQFN Exposed Pad

ECAD Model:

Description:

4V ~ 38V 16-Pin DC to DC converter IC SWITCHING REGULATOR 1 Outputs 235kHz ~ 750kHz Transistor Driver
