Analog Devices Inc. ADL5802-EVALZADL5802 High IP3 100 MHz TO 6 GHz Active Mixer Evaluation Board

The Analog Devices ADL5802-EVALZ Evaluation Board is a versatile tool for testing and evaluating the performance of the ADL5802 dual-channel active mixer. This board is designed for communications and telecom applications, and is capable of operating from 100 MHz to 6 GHz. It features two independent RF inputs, two independent LO inputs, and two independent IF outputs. The board also includes a wide range of features such as a power detector, a gain control, and a temperature sensor. The ADL5802-EVALZ Evaluation Board is an ideal tool for testing and evaluating the performance of the ADL5802 active mixer in a variety of applications.
