Analog Devices Inc. EVAL-RS485FD8EBZANALOG DEVICES EVAL-RS485FD8EBZEvaluation Board for Full Duplex RS485 Transceiver in 8 Lead SOIC Package

The Analog Devices EVAL-RS485FD8EBZ is an evaluation board designed for use with the ADM3077E Half-Duplex RS-485 Transceiver in an 8-lead SOIC package. This board is ideal for testing and evaluating the performance of the ADM3077E in a variety of communications and telecom applications. The board features a DB9 connector for easy connection to a PC, and includes a power supply, a USB-to-RS485 converter, and a set of jumpers for configuring the board. The board also includes a set of LEDs to indicate the status of the transceiver, and a set of test points for monitoring the transceiver's signals. The board is designed to be used with the ADM3077E, but can also be used with other RS-485 transceivers.
