Maxim Integrated MAX14591EVKIT#EVAL KIT MAX14591 (HIGH SPEED OP

The MAX14591EVKIT-EVKIT# is an evaluation kit for the MAX14591 high-speed, open-drain capable logic-level translator, communications and telecom IC. This kit includes a MAX14591EVKIT# board, a MAX14591 IC, and a USB cable. The MAX14591 IC is a low-power, high-speed, open-drain capable logic-level translator that is designed to provide a low-voltage logic interface between two different voltage domains. The IC is capable of translating between 1.8V, 2.5V, 3.3V, and 5V logic levels. The MAX14591EVKIT# board provides a platform for evaluating the MAX14591 IC and its features. The board includes a USB connector for connecting to a PC, as well as a variety of test points and jumpers for configuring the IC. The board also includes a power supply circuit for providing the necessary power to the IC.
