The Texas Instruments UA7812 series Linear Voltage Regulators are fixed-voltage integrated-circuit voltage regulators designed for a wide range of applications. They are available in fixed 5-V/8-V/10-V/12-V/15-V/24-V applications1. The UA78 is a 1.5-A, 38-V, linear voltage regulator
Texas Instruments UA7812 series Linear Voltage Regulators
Comprehensive Guide to UA7812 Integrated Circuits (ICs) Linear Voltage Regulators
In this post, you will find the Key Component Features, Diverse Applications, Associated Series Parts, Technical Documents(PDF Datasheets, User Guides), Frequently asked questions, and Related Series of Texas Instruments UA7812 series Linear Voltage Regulators products.
FEATURES
- 1.5-A, 38-V, linear voltage regulator
- Designed for a wide range of applications
Applications
- Medical
- Industrial transport (non-car & non-light truck)
Associated Products
| Part Number | Description | Stock | RFQ |
|---|---|---|---|
| UA7812CKTER | IC REG LIN 12V 1.5A 3POWERFLEX | 1800 | RFQ |
| UA7812CKCT | TEXAS INSTRUMENTS UA7812CKCT Linear Voltage Regulator, 7812, Fixed, 14.5V To 30V In, 12V And 1.5A Out, TO-220-3 | 13 | BUY |
| UA7812CKCS | IC REG LINEAR 12V 1.5A TO220-3 | 36 | RFQ |
| UA7812CKTTR | IC REG LIN 12V 1.5A DDPAK/TO263 | 18 | BUY |
| UA7812CKCSE3 | IC REG LINEAR 12V 1.5A TO220-3 | 50000 | BUY |
| UA7812CKTTRG3 | IC REG LIN 12V 1.5A DDPAK/TO263 | 309 | RFQ |
| UA7812CKC | IC REG LINEAR 12V 1.5A TO220-3 | 222 | RFQ |
Technical Documents
- TO-220, SOT-23 Pkg Cu Wire Base 27/Sep/2013
- Copper Wire Base Metal 29/Sep/2014
- Copper Wire Revision A 19/Jan/2015
- Site Chg 25/Jan/2016
- Qualification Carrier Tape 13/Mar/2014
- UA7812CKTTR-Texas-Instruments-datasheet-12079246.pdf
- UA7812CKTTR-Texas-Instruments-datasheet-36835626.pdf
- UA7812CKTTR-Texas-Instruments-datasheet-10255686.pdf
- UA7812CKTTR-Texas-Instruments-datasheet-123581.pdf
- UA7812CKTTR-Texas-Instruments-datasheet-14168816.pdf
- UA7812CKCSE3-Texas-Instruments-datasheet-12079246.pdf
- UA7812CKCSE3-Texas-Instruments-datasheet-123581.pdf
Related Series
Analog Devices ADP70xx series Linear regulators
29 March 20231617
Diodes Incorporated AP734 series Low Dropout Regulators
03 April 2023289
Texas Instruments UA7812 series Linear Voltage Regulators
31 July 2023329
Frequently Asked Questions
What are the similar products or Substitute Components of Texas Instruments UA7812 series Linear Voltage Regulators
LM7812: This is a series of linear voltage regulators from Texas Instruments that offer similar features to the UA7812 series, including a fixed output voltage of 12V and a maximum output current of 1A. The LM7812 is a popular alternative to the UA7812 and is widely available. LM317: This is an adjustable linear voltage regulator from Texas Instruments that can be used as a substitute for the UA7812 in some applications. The LM317 allows for adjustable output voltage using external resistors, providing flexibility in setting the output voltage to suit the specific needs of the application.
How do I use Texas Instruments UA7812 series Linear Voltage Regulators in my project?
The first considerations for choosing a linear regulator are input voltage (VI), output voltage (VO), and output current (IO). These are necessary for selecting the appropriate linear regulator for an application. Other very necessary, although often overlooked, considerations in linear regulator design include dropout voltage, quiescent current, line regulation, load regulation, transient response, and thermal performance
