MikroElektronika MIKROE-3329TEMP-LOG 4 CLICK
The MikroElektronika MIKROE-3329 Temp-Log 4 Click Board is a consumer electronics device based on the SE97B temperature sensor with integrated EEPROM. It is designed to measure temperature in a wide range of applications, from industrial to medical. The board features a high-accuracy temperature sensor with a resolution of 0.0625°C and a temperature range of -40°C to +125°C. It also includes an integrated EEPROM for storing temperature data, allowing for long-term temperature monitoring. The board is easy to use and can be connected to a microcontroller or other device via a mikroBUS socket. It is ideal for applications such as temperature monitoring, HVAC systems, and medical equipment.
- TypeParameter
- Factory Lead Time4 Weeks
- Part StatusActive
- Moisture Sensitivity Level (MSL)1 (Unlimited)
- TypeSensor
- FunctionTemperature
- Utilized IC / PartSE97B
- ContentsBoard(s)
- PlatformmikroBUS™ Click™
- RoHS StatusROHS3 Compliant
