Analog Devices Inc. AD9642-170EBZANALOG DEVICES AD9642-170EBZAD9642, ADC, SPI, EVALUATION BOARD
Applications:
Data Conversion >
Analog to Digital Conversion
End Products:
AutomotiveDigital RadioWiMAX/Wireless BroadbandAV ReceiverUltrasound ImagingActive AntennaSoftware Defined RadioCommunications and Telecom
ECAD Model:
Description
The Analog Devices AD9642-170EBZ Evaluation Board is a versatile platform for evaluating the performance of the AD9642BCPZ-170, a 14-bit, 170 MSPS analog-to-digital converter. This board is designed for use in external, automotive, and transportation applications, and features an SPI interface for setup and control. The board includes a wide range of features, such as a low-noise power supply, a high-speed clock generator, and a wide range of input and output connectors. The board also includes a comprehensive set of software tools for configuring and testing the AD9642BCPZ-170. The AD9642-170EBZ Evaluation Board is an ideal platform for evaluating the performance of the AD9642BCPZ-170 in a variety of applications.
Specifications
Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .
- TypeParameter
- Number of Pins0
- PackagingBulk
- Part StatusObsolete
- Moisture Sensitivity Level (MSL)1 (Unlimited)
- Max Operating Temperature85°C
- Min Operating Temperature-40°C
- Base Part NumberAD9642
- Operating Supply Voltage6V
- Number of Channels1
- InterfaceLVDS, Parallel, SPI, USB
- Operating Supply Current2A
- Number of Bits14
- Max Input Voltage1.75V
- Utilized IC / PartAD9642
- Supplied ContentsBoard(s)
- Data InterfaceLVDS - Parallel, SPI
- Resolution1.75 B
- Sampling Rate170 Msps
- Evaluation KitYes
- Sampling Rate (Per Second)170M
- Number of A/D Converters1
- Input Capacitance2.5pF
- Input Range1.4 ~ 2Vpp
- Power (Typ) @ Conditions311mW @ 170MSPS
- REACH SVHCNo SVHC
- RoHS StatusROHS3 Compliant
- Lead FreeContains Lead
