Analog Devices Inc. EVAL-ADF4252EBZ2BOARD EVAL ADF4252 NO VCO/FILTER

Analog Devices Inc. EVAL-ADF4252EBZ2 Reference Design 2

Analog Devices Inc. EVAL-ADF4252EBZ2 Reference Design 1

Applications:

Clock and Timing >

PLL Clock Generator

End Products:

Instrumentation and MeasurementClock and Timing Devices

ECAD Model:

Buy

Description

The EVAL-ADF4252EBZ2 Evaluation Board from Analog Devices is a versatile tool for evaluating the performance of the ADF4252 Dual Fractional/Integer Frequency Synthesizer. This board features a wide range of instrumentation and measurement capabilities, including a frequency range of up to 4.4 GHz, a wide range of output power levels, and a low phase noise of -90 dBc/Hz. It also includes a USB interface for easy connection to a PC, and a graphical user interface for easy configuration and control. The board is ideal for applications such as wireless communications, test and measurement, and instrumentation.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .

Type
Parameter
Lifecycle Status
PRODUCTION (Last Updated: 4 weeks ago)
Factory Lead Time
8 Weeks
Mount
Cable
Number of Pins
0
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Type
Timing
Frequency
3GHz
Base Part Number
ADF4252
Function
Frequency Synthesizer
Operating Supply Voltage
9V
Interface
Parallel
Operating Supply Current
13mA
Utilized IC / Part
ADF4252
Supplied Contents
Board(s), Cable(s)
Evaluation Kit
Yes
Primary Attributes
Dual Fractional-N PLL
Embedded
No
Secondary Attributes
Board Excludes Loop Filter and VCO
REACH SVHC
No SVHC
Radiation Hardening
No
RoHS Status
ROHS3 Compliant
Lead Free
Contains Lead

0 Similar Products Remaining
