Description

The Analog Devices AD9523-PCBZ Evaluation Board is a versatile tool for evaluating the AD9523 Clock Generator, Communications and Telecom IC. This evaluation board is designed to provide a comprehensive platform for testing and evaluating the features and performance of the AD9523. It includes a wide range of features such as a high-performance clock generator, a low-noise voltage-controlled oscillator (VCO), a low-jitter clock distribution network, and a wide range of programmable output frequencies. The board also includes a variety of test points and connectors for easy connection to external test equipment. The AD9523-PCBZ Evaluation Board is an ideal tool for evaluating the performance of the AD9523 in a variety of applications.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .

Type
Parameter
Number of Pins
0
Packaging
Bulk
Part Status
Obsolete
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Type
Timing
Frequency
400MHz
Base Part Number
AD9523
Function
Clock Generator
Operating Supply Voltage
6V
Interface
USB
Utilized IC / Part
AD9523
Supplied Contents
Board(s)
Evaluation Kit
Yes
Primary Attributes
On Board PLL Loop Filter
Embedded
No
Secondary Attributes
On-Board LEDs
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
Lead Free
Contains Lead

0 Similar Products Remaining
