Analog Devices Inc. ADP2302-EVALZANALOG DEVICES ADP2302-EVALZEvaluation Board for ADP2302 Step Down DC to DC Regulator

The Analog Devices ADP2302-EVALZ Evaluation Board is designed to evaluate the performance of the ADP2302, a 2 A/3 A, 20 V, nonsynchronous step-down regulator for communications and telecom power supplies. The board features a wide input voltage range of 4.5 V to 20 V, adjustable output voltage range of 0.8 V to 20 V, and a high efficiency of up to 95%. It also includes a wide range of protection features such as over-current protection, over-voltage protection, and thermal shutdown. The board is designed to be used with the ADP2302 regulator and is ideal for evaluating the performance of the regulator in a variety of applications.
