Analog Devices Inc. EVAL-AD7682EDZEVALUATION BOARD FOR AD7682/89/99/7949 PULSAR ADCS

Analog Devices Inc. EVAL-AD7682EDZ Reference Design 3
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 1
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 2
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 3
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 1
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 1
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 2
Analog Devices Inc. EVAL-AD7682EDZ Reference Design 3

Applications:

Data Conversion >

Analog to Digital Conversion

End Products:

Instrumentation and MeasurementData Acquisition SystemIndustrial ControlPortable Medical InstrumentationInstrumentation and MeasurementPower Line CommunicationGPS

ECAD Model:

Buy

Description

The EVAL-AD7682EDZ Evaluation Board from Analog Devices is designed for use with the 20-lead PulSAR AD7982 16-bit PulSAR analog to digital converter family. This board provides a complete platform for evaluating the performance of the AD7982 family of converters. It includes a power supply, a reference voltage, and a variety of connectors and jumpers for easy connection to external circuitry. The board also includes a USB interface for easy connection to a PC for data acquisition and control. The board is ideal for instrumentation and measurement applications, providing a convenient and cost-effective way to evaluate the performance of the AD7982 family of converters.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .
  • Type
    Parameter
  • Lifecycle Status
    PRODUCTION (Last Updated: 3 weeks ago)
  • Factory Lead Time
    8 Weeks
  • Number of Pins
    10
  • Packaging
    Box
  • Series
    PulSAR®
  • Part Status
    Active
  • Moisture Sensitivity Level (MSL)
    1 (Unlimited)
  • Max Operating Temperature
    85°C
  • Min Operating Temperature
    -40°C
  • Base Part Number
    AD7682
  • Operating Supply Voltage
    5.5V
  • Interface
    SPI, Serial
  • Number of Bits
    16
  • Utilized IC / Part
    AD7682
  • Supplied Contents
    Board(s)
  • Data Interface
    Serial
  • Resolution
    2 B
  • Sampling Rate
    250 ksps
  • Evaluation Kit
    Yes
  • Sampling Rate (Per Second)
    250k
  • Number of A/D Converters
    1
  • Input Range
    ±VREF
  • Power (Typ) @ Conditions
    12.5mW @ 250kSPS 5V
  • REACH SVHC
    No SVHC
  • Radiation Hardening
    No
  • RoHS Status
    ROHS3 Compliant
  • Lead Free
    Contains Lead
