Description

The Analog Devices EVAL-ADF7020DBZ2 Evaluation Board is designed to evaluate the performance of the ADF7020 ISM Band Transceiver. This board is ideal for industrial, scientific, and medical (ISM) applications. It features a wide range of features, including a low-power, low-cost, high-performance transceiver, a wide range of operating frequencies, and a wide range of modulation schemes. The board also includes a variety of test points and connectors for easy evaluation and testing. The board is also designed to be compatible with a variety of development tools, including the Analog Devices VisualDSP++ and the Analog Devices ADF7020 Evaluation Kit.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .
  • Type
    Parameter
  • Factory Lead Time
    8 Weeks
  • Part Status
    Active
  • Moisture Sensitivity Level (MSL)
    1 (Unlimited)
  • Type
    Transceiver, ASK
  • Frequency
    862MHz~870MHz
  • Base Part Number
    ADF7020
  • Supplied Contents
    Board(s), Accessories
  • RoHS Status
    ROHS3 Compliant
0 Similar Products Remaining
Technical Documents

Associated Products

Part NumberManufacturerDescriptionStockRFQ
Analog Devices Inc.ANALOG DEVICES ADF7020BCPZ TRANSCEIVER250BUY
Murata ElectronicsMURATA LFL18924MTC1A052FILTER25BUY
Analog Devices Inc.RF Transceiver ASK/FSK 2.5V/3.3V 48-Pin LFCSP EP T/R354BUY
Analog DevicesRF Transceiver ASK/FSK 2.5V/3.3V 48-Pin LFCSP EP T/R0RFQ
