Analog Devices Inc. EVAL-CN0178-SDPZANALOG DEVICES EVAL-CN0178-SDPZADL5902, PWR MEASUREMENT, EVAL BOARD
Applications:
Wireless Communication >
RF Power Detectors
End Products:
Military and AerospaceDefense Electronics SystemsWireless InfrastructureElectronic Surveillance & CountermeasuresRadar SystemInstrumentation and Measurement
ECAD Model:
Description
The Analog Devices EVAL-CN0178-SDPZ is a software-calibrated, RF power measurement system evaluation board based on the ADL5902 military and aerospace grade device. It is designed to measure RF power from 50 MHz to 9 GHz, with a wide dynamic range of up to +20 dBm. The board features a USB interface for easy connection to a PC, and includes a software package for calibration and data logging. It is ideal for applications such as RF power amplifier testing, antenna testing, and wireless communication system testing. The board is also RoHS compliant and is suitable for use in harsh environments.
Specifications
Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .
- TypeParameter
- Lifecycle StatusPRODUCTION (Last Updated: 1 week ago)
- Factory Lead Time8 Weeks
- Number of Pins0
- Part StatusActive
- Moisture Sensitivity Level (MSL)1 (Unlimited)
- TypePower Detector
- Frequency50MHz~9GHz
- Operating Supply Voltage6V
- Supplied ContentsBoard(s)
- Evaluation KitYes
- REACH SVHCNo SVHC
- RoHS StatusROHS3 Compliant
- Lead FreeContains Lead
