ON Semiconductor NCP59744MN2ADJGEVBEVAL BOARD NCP59744MN2ADJG
Applications:
Power Supplies >
DC to DC Single Output Power Supplies
End Products:
Consumer ElectronicsConsumer ElectronicsFPGA SolutionsIndustrialPower Supplies
ECAD Model:
Description
The ON Semiconductor NCP59744MN2ADJGEVB-ADJGEVB is a precision ultra-low dropout voltage regulator evaluation board designed for consumer electronics applications. It features a wide input voltage range of 2.5V to 5.5V and a low dropout voltage of 0.2V. The board also includes an adjustable output voltage range of 0.8V to 5.0V, allowing for precise voltage regulation. The board is designed to provide a high level of accuracy and stability, making it ideal for use in consumer electronics applications.
Specifications
ON Semiconductor technical specifications, attributes, parameters and parts with similar specifications to ON Semiconductor .
- TypeParameter
- Factory Lead Time126 Weeks
- PackagingBox
- Published2014
- Part StatusActive
- Moisture Sensitivity Level (MSL)1 (Unlimited)
- Max Operating Temperature125°C
- Min Operating Temperature-40°C
- Voltage - Output1.2V
- Utilized IC / PartNCP59744
- Supplied ContentsBoard(s)
- Evaluation KitYes
- Regulator TypePositive Adjustable
- Board TypeFully Populated
- Channels per IC1 - Single
- RoHS StatusROHS3 Compliant
