Description

The Analog Devices AD9525/PCBZ-VCO Evaluation Board is designed to evaluate the performance of the AD9525 2950 MHz VCO Clock Generator in the industrial temperature range. This evaluation board features a wide range of features, including a low-noise power supply, a high-performance VCO, and a wide range of test points for easy evaluation. The board also includes a comprehensive set of documentation, including a user guide, schematics, and layout diagrams. This evaluation board is ideal for evaluating the performance of the AD9525 2950 MHz VCO Clock Generator in industrial applications.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .

Type
Parameter
Lifecycle Status
CONTACT ADI (Last Updated: 1 month ago)
Factory Lead Time
10 Weeks
Number of Pins
0
Packaging
Bulk
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Type
Timing
Frequency
3.6GHz
Base Part Number
AD9525
Function
Clock Generator
Operating Supply Voltage
3.3V
Utilized IC / Part
AD9525
Supplied Contents
Board(s)
Evaluation Kit
Yes
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
Lead Free
Contains Lead
