Description

The Analog Devices EVAL-AD7677EDZ is an evaluation board designed for use with the AD7677 PulSAR 48 Lead ADC. This board is ideal for medical and healthcare applications, providing a convenient platform for testing and evaluating the performance of the ADC. It features a wide range of features, including a high-speed, low-noise, low-power, and low-distortion signal path, as well as a wide range of input and output connectors. The board also includes a variety of test points and jumpers for easy debugging and evaluation. Additionally, the board is designed to be compatible with a variety of development tools, making it easy to integrate into existing systems.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .

Type
Parameter
Lifecycle Status
LAST TIME BUY (Last Updated: 3 weeks ago)
Package / Case
Module
Number of Pins
0
Packaging
Bulk
Series
PulSAR®
Part Status
Obsolete
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Max Operating Temperature
85°C
Min Operating Temperature
-40°C
Base Part Number
AD7677
Operating Supply Voltage
5.25V
Interface
Parallel, Serial
Number of Bits
16
Utilized IC / Part
AD7677
Supplied Contents
Board(s)
Data Interface
Serial, Parallel
Resolution
2 B
Sampling Rate
1 Msps
Evaluation Kit
Yes
Sampling Rate (Per Second)
1M
Number of A/D Converters
1
Input Range
±VREF
REACH SVHC
No SVHC
RoHS Status
ROHS3 Compliant
Lead Free
Contains Lead

0 Similar Products Remaining
