Description

The Analog Devices EVAL-ADG5436FEBZ Evaluation Board is designed to evaluate the performance of the ADG5436F Overvoltage Protected Dual SPDT Switch. This board is ideal for use in communications and telecom applications, providing a reliable and cost-effective solution for switching and routing signals. The board features two independent SPDT switches, each with a maximum voltage rating of 28V and a maximum current rating of 1A. The board also includes a wide range of protection features, such as overvoltage protection, ESD protection, and reverse polarity protection. The board is easy to use and provides a convenient platform for evaluating the performance of the ADG5436F switch.

Specifications

Analog Devices Inc. technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. .
  • Type
    Parameter
  • Lifecycle Status
    PRODUCTION (Last Updated: 2 weeks ago)
  • Factory Lead Time
    8 Weeks
  • Mount
    PCB
  • Number of Pins
    0
  • Part Status
    Active
  • Moisture Sensitivity Level (MSL)
    1 (Unlimited)
  • Type
    Interface
  • Base Part Number
    ADG5436
  • Function
    Analog Switch
  • Utilized IC / Part
    ADG5436F
  • Supplied Contents
    Board(s)
  • Evaluation Kit
    Yes
  • Primary Attributes
    2 x SPDT Analog Switch
  • RoHS Status
    ROHS3 Compliant
  • Lead Free
    Contains Lead
0 Similar Products Remaining
