Linear Technology/Analog Devices DC1277ALTC3670EDDB - SYNCHRONOUS 400MA,
Applications:
Power Supplies >
DC to DC Multi-Output Power Supplies
End Products:
Consumer ElectronicsPortableFPGA SolutionsCellular Phone
ECAD Model:
Description
The Analog Devices DC1277A-A LTC3670 Demo Board is a monolithic 400mA buck regulator with dual 150mA LDOs in a 3mm x 2mm DFN package. It is designed for use in consumer electronics applications, providing a high level of efficiency and power density. The buck regulator is capable of providing up to 400mA of output current, while the dual LDOs can provide up to 150mA each. The board also features a wide input voltage range of 2.5V to 5.5V, making it suitable for a variety of applications. The board is also equipped with a variety of protection features, including over-voltage, over-current, and thermal protection. The board is also RoHS compliant, making it an ideal choice for consumer electronics applications.
Specifications
Linear Technology/Analog Devices technical specifications, attributes, parameters and parts with similar specifications to Linear Technology/Analog Devices .
- TypeParameter
- Factory Lead Time8 Weeks
- Voltage-Input2.5V~5.5V
- Part StatusActive
- Moisture Sensitivity Level (MSL)1 (Unlimited)
- Current - Output400mA 150mA 150mA
- Voltage - Output1.2V 2.8V 3.3V
- Utilized IC / PartLTC3670
- Supplied ContentsBoard(s)
- Board TypeFully Populated
- Main PurposeDC/DC, Step Down with LDO
- Outputs and Type3, Non-Isolated
- Regulator TopologyBuck
- RoHS StatusROHS3 Compliant
