Maxim Integrated MAX14778EVKIT#Switch IC Development Tools Eval Kit MAX14778 (Dual +/-25V Above- and Below-the-Rails 4:1 AnalogMultiplexer)

The MAX14778EVKIT-EVKIT# is an evaluation kit for the MAX14778 Dual ±25V Above- and Below-the-Rails 4:1 Analog Multiplexer, Audio Switch. This kit includes a MAX14778 evaluation board, a USB-to-I2C interface board, and a USB cable. The MAX14778 is a low-power, low-voltage, 4:1 analog multiplexer/audio switch that can switch between two audio sources with a single control signal. It features a wide ±25V common-mode voltage range, low on-resistance, and low power consumption. The evaluation board also includes a power supply, a headphone jack, and a 3.5mm audio jack for easy testing.
