Maxim Integrated MAX5X05EVKIT#EV KIT FOR MAX5705 AND MAX5805 1

The MAX5X05EVKIT-EVKIT# is an evaluation kit for the MAX5705B/MAX5805B Ultra-Small, Single-Channel, 12-Bit Buffered Output Voltage DAC with Internal Reference and SPI Interface. This kit provides a convenient platform for evaluating the performance of the MAX5705B/MAX5805B DACs. It includes a MAX5705B/MAX5805B evaluation board, a USB-to-SPI adapter, and a USB cable. The evaluation board features a 12-bit DAC with an internal reference, a SPI interface, and a buffered output voltage. It also includes a potentiometer for adjusting the output voltage, and a jumper for selecting the reference voltage. The USB-to-SPI adapter allows for easy connection to a PC for programming and data acquisition. The kit is ideal for instrumentation and measurement applications.
