Maxim Integrated MAX9293COAXEVKIT#EVKIT GMSL SERIALIZER FOR COAX A

The MAX9293COAXEVKIT-COAXEVKIT# is an evaluation kit for the MAX9293 3.12 Gbps GMSL Serializer for Coax or STP Output and HDMI Input, Automotive and Transportation Applications. This kit provides a complete platform for evaluating the MAX9293 serializer, which is designed to convert an HDMI input into a GMSL serial data stream for transmission over coax or shielded twisted pair (STP) cables. The kit includes a MAX9293 evaluation board, a MAX9293 daughter card, a MAX9293 coax cable, and a USB-to-I2C adapter. The evaluation board features a USB-to-I2C adapter, a power supply, and a HDMI input connector. The MAX9293 daughter card provides a coax or STP output connector, a power supply, and a HDMI output connector. The MAX9293 coax cable is used to connect the evaluation board to the daughter card. The USB-to-I2C adapter allows the user to control the MAX9293 serializer via a PC. This evaluation kit is ideal for automotive and transportation applications that require a reliable and high-speed serial data transmission over coax or STP cables.
