Description

The NXP Semiconductors TWR-K22F120M is a Kinetis K22 Tower System Module based on the MK22FN512 MCU. It is designed for use in consumer electronics applications, providing a powerful and efficient platform for embedded development. The module features an ARM Cortex-M4 core with a maximum clock speed of 120 MHz, 512 KB of Flash memory, and 128 KB of SRAM. It also includes a variety of peripherals, such as a 12-bit ADC, a 12-bit DAC, a USB 2.0 controller, and a CAN controller. The module is also equipped with a variety of communication interfaces, including Ethernet, CAN, and USB. The module is designed to be used with the Kinetis K22 Tower System, which provides a comprehensive development environment for embedded applications.

Specifications

NXP USA Inc. technical specifications, attributes, parameters and parts with similar specifications to NXP USA Inc. .

Type
Parameter
Factory Lead Time
14 Weeks
Mounting Type
Fixed
Series
Kinetis
Published
2002
Part Status
Active
Moisture Sensitivity Level (MSL)
1 (Unlimited)
Type
MCU 32-Bit
Core Processor
ARM® Cortex®-M4
Utilized IC / Part
K22
Contents
Board(s), Cable(s)
Board Type
Evaluation Platform
Platform
Tower System
RoHS Status
ROHS3 Compliant

0 Similar Products Remaining
