STMicroelectronics SPC560PADPT100SDaughter Cards & OEM Boards Socketed Mini Mod SPC560P QFP100 Req

STMicroelectronics SPC560PADPT100S Reference Design 2
STMicroelectronics SPC560PADPT100S Reference Design 1
STMicroelectronics SPC560PADPT100S Reference Design 2
STMicroelectronics SPC560PADPT100S Reference Design 1
STMicroelectronics SPC560PADPT100S Reference Design 1
STMicroelectronics SPC560PADPT100S Reference Design 2

Applications:

Embedded System >

Microcontroller

End Products:

AutomotiveAutomotive - Body ElectronicsSafety

ECAD Model:

Buy

Description

The STMicroelectronics SPC560PADPT100S-S, SPC560PADPT100S, Daughter/Adapter Board is designed for use with the SPC560P44L3 and SPC560P50L3 SPC560 series 512KB/1MB MCU devices in QFP100 package. This board is ideal for automotive and transportation applications, providing a convenient and reliable way to connect the MCU to other components. It features a wide range of connectors, including a USB port, CAN bus, and a JTAG connector, as well as a power supply and a reset button. The board also includes a set of LEDs for debugging and monitoring purposes. The board is designed to be used in a wide range of temperatures, from -40°C to +125°C, making it suitable for use in harsh environments.

Specifications

STMicroelectronics technical specifications, attributes, parameters and parts with similar specifications to STMicroelectronics .
  • Type
    Parameter
  • Mounting Type
    Fixed
  • Package / Case
    Module
  • Part Status
    Active
  • Moisture Sensitivity Level (MSL)
    1 (Unlimited)
  • Type
    MCU 32-Bit
  • Core Processor
    e200
  • Utilized IC / Part
    SPC560P
  • Evaluation Kit
    Yes
  • Contents
    Board(s)
  • Board Type
    Evaluation Platform
  • RoHS Status
    ROHS3 Compliant
