LM833N Operational Amplifier: Audio Amplifier, Datasheet, Pinout

Q: What is an LM 833N Amplifier?

LM833N is basically a dual general-purpose amplifier. It is usually designed for audio systems. LM 833 is the most common Integrated Circuit (IC) available in the market nowadays. This is due to its low cost and high-performance activities. It uses bipolar technology.

Q: What are the characteristics of the lm833N output stage?

The LM833N output stage exhibits no dead-band crossover distortion, large output voltage swing, excellent phase and gain margins, low open-loop high-frequency output impedance and symmetrical source/sink AC frequency response. Low Input Offset Voltage: 0.3 mV

Sophie

Published: 30 December 2021 | Last Updated: 30 December 2021

4790

datasheet pdf and product details from stock available at Utmel

Purchase Guide

The LM833N is a monolithic dual operational amplifier. This article will unlock more details about LM833. There is a huge range of Semiconductors, Capacitors, Resistors and ICs in stock. Welcome RFQ!

A comparison between these two ICs in my Angry Charlie clone pedal. Same settings. You hear riffs first, then solos.

LM833N vs. JRC4580D in Angry Charlie guitar pedal

Catalog

LM833N Pinout

LM833N Pinout.jpg

LM833N Pinout

LM833N CAD Model

Symbol

LM833N Symbol.jpg

LM833N Symbol

Footprint

LM833N Footprint.jpg

LM833N Footprint

3D Model

LM833N 3D Model

LM833N Description

The LM833N is a monolithic dual operational amplifier particularly well-suited to audio applications. It offers low voltage noise (4.5 nV/√Hz) and high-frequency performances (15 MHz gain-bandwidth product, 7 V/µs slew rate). In addition, the LM833N has very low distortion (0.002%) and excellent phase/gain margins.

Also, The LM833N is a dual general-purpose operational amplifier with a strong focus on audio system performance. This dual amplifier IC employs novel circuit and processing techniques to provide low noise, high speed, and wide bandwidth without requiring additional external components or compromising stability. The LM833N is ideal for all preamp and high-level stages in PCM and HiFi systems since it is internally adjusted for all closed-loop gains. Industry-standard dual operating amplifiers are pin-for-pin compatible with the LM833N.

LM833N Feature

■ Low voltage noise: 4.5 nV/√Hz

■ High gain bandwidth product: 15 MHz

■ High slew rate: 7 V/µs

■ Low distortion: 0.002%

■ Excellent frequency stability

■ ESD protection 2 kV

LM833N Application

■ Audio systems

■ Preamplification, filtering

LM833N Circuit Diagram

LM833N Typical Application Circuit.jpg

LM833N Typical Application Circuit

Specifications

technical specifications, attributes, parameters and parts with similar specifications to .

Type
Parameter

0 Similar Products Remaining

Parts with Similar Specs

LM833N Package

LM833N Package.jpg

LM833N Package

LM833N Manufacturer

STMicroelectronics is a global independent semiconductor company and is a leader in developing and delivering semiconductor solutions across the spectrum of microelectronics applications. An unrivalled combination of silicon and system expertise, manufacturing strength, Intellectual Property (IP) portfolio and strategic partners positions the Company at the forefront of System-on-Chip (SoC) technology and its products play a key role in enabling today's convergence trends.

Trend Analysis

Frequently Asked Questions

What is an LM 833N Amplifier?

LM833N is basically a dual general-purpose amplifier. It is usually designed for audio systems. LM 833 is the most common Integrated Circuit (IC) available in the market nowadays. This is due to its low cost and high-performance activities. It uses bipolar technology.

What are the characteristics of the lm833N output stage?

The LM833N output stage exhibits no dead-band crossover distortion, large output voltage swing, excellent phase and gain margins, low open-loop high-frequency output impedance and symmetrical source/sink AC frequency response. Low Input Offset Voltage: 0.3 mV
